Munder Difflin's Architecture: Two Data Planes, One Renderer

Most of what Munder Difflin does follows from a single architectural choice, so it’s worth walking through. The harness runs many real Claude Code agents and shows you two things about each: the exact terminal output, and a live picture of what it’s doing. Those are different kinds of data, so they travel on two separate planes that meet in one renderer. Here’s the whole shape.

The load-bearing decision: two planes #

┌──────────────────── Electron Renderer (React + Pixi) ───────────────────┐
│   Office floor (Pixi.js)            Terminal view (xterm.js)             │
│        ▲ avatar state                     ▲ pty bytes                    │
└────────┼──────────────────────────────────┼────────────────────────────┘
         │ IPC                               │ IPC
   ┌─────┴───────────────┐            ┌──────┴──────────────┐
   │   Event Plane       │            │  Terminal Plane     │
   │ hooks + hive router │            │     node-pty        │
   └─────▲───────────────┘            └──────▲──────────────┘
         │ JSON events                       │ raw bytes
   ┌─────┴───────────────────────────────────┴──────────────┐
   │            Claude Code processes (one per agent)        │
   └────────────────────────────────────────────────────────┘

Each agent is one real claude process. From it we read two streams:

• a byte stream — exactly what the shell printed, and
• an event stream — structured “I’m about to use this tool,” “a message routed,” “I stopped.”

Keeping them separate is the whole trick. Let’s take each plane, then how they converge.

The terminal plane (node-pty) #

The terminal plane is about fidelity. Each agent runs in a real pseudo-terminal via node-pty, so its shell behaves byte-for-byte like a normal terminal — colors, prompts, full-screen TUIs, all authentic. The main process owns the PTY and forwards its output to the renderer over IPC on a per-session channel; keystrokes from the UI travel back the same way. The renderer paints it with a pooled xterm.js terminal per agent (the technique behind rendering many live terminals).

What the terminal plane gives you: the unfiltered truth of what each agent did. What it can’t easily give you: a reliable “which tool is running right now?” without scraping and guessing at output. That’s the other plane’s job.

The event plane (hooks + hive) #

The event plane is about structure. It has two sources, both feeding the main process:

Claude Code hooks. Each agent is launched with lifecycle hooks wired through a tiny shim that forwards every event — PreToolUse, PostToolUse, Stop, Notification — to a Unix domain socket the main process listens on. These are clean, typed signals: “about to run Bash,” “finished editing,” “idle and waiting.” No output parsing required. (See Claude Code hooks, explained.)

The hive. The coordination layer — per-agent mailboxes, a message router, single-committer git, and shared memory — emits its own events as it works: a message routed from A to B, an item escalated to the human. The GOD orchestrator lives here as the intelligence; the main process is the mechanism that moves messages and commits state.

Both sources land in the main process, which forwards structured events to the renderer. There they drive the office floor: avatars walk to stations on tool events, envelopes fly on message events.

Why both planes (the rationale) #

The temptation is to pick one. Each alone is insufficient:

• Hooks alone don’t give you the raw stream the user expects to see — you’d know an agent ran a command but not what it printed.
• The terminal stream alone can’t tell you which tool is running without fragile output parsing — you’d see bytes but have to guess at meaning.

Together they’re complementary: the office floor is event-driven (precise, structured, cheap to render), and the terminal view is byte-for-byte authentic (the full detail when you want it). Two planes, two questions, both answered well.

One renderer convergence #

Both planes terminate in a single Electron renderer running React and Pixi.js:

• React owns the app shell, panels, and the xterm.js terminal views (the terminal plane).
• Pixi.js owns the office floor — avatars, the Tiled map, flying envelopes (the event plane), in one camera-controlled world updated by a single ticker (the design in visualizing AI agents with Pixi.js).

The bridge between the main process and the renderer is a typed preload API exposed over Electron’s context bridge — the renderer calls into it to spawn/write/resize PTYs and read hive state, and subscribes to it for incoming terminal bytes and hive events. Crucially, the renderer never touches the filesystem, git, or the agents directly; it only talks to the main process. That keeps a hard line between mechanism (main process: PTYs, sockets, git, routing) and presentation (renderer: React + Pixi).

Why this architecture holds up #

A few properties fall out of the two-plane design:

• Separation of concerns. Fidelity and structure are independent problems solved independently. You can improve terminal rendering without touching the event pipeline, and vice versa.
• The main process is the single source of authority. PTYs, the hook socket, the hive’s git repo, and the memory layer all live in one place; the renderer is a consumer. That’s what makes the single-committer git pattern and safe IPC possible.
• Real, not simulated. Because the event plane carries actual hook and router events, the visualization can’t drift from reality — it is reality, rendered.

It’s the architecture that lets “a hive of Claude Code agents” be both something you can read (the terminals) and something you can watch (the floor) — which is the heart of what a multi-agent harness is.

FAQ #

Where does memory fit in the two planes? Alongside the event plane’s hive layer. The shared semantic memory is driven by the main process (a CLI it points each agent at), and recall happens in the agents themselves — it’s part of the coordination mechanism, not a third UI plane.

Could you add a third plane? You could, but the discipline is to keep planes orthogonal. New signals usually fit the event plane (more structured events) or the terminal plane (more byte streams) rather than needing a new one.

---

Munder Difflin’s two-plane architecture — authentic node-pty terminals plus an event-driven Pixi.js floor, converging in one renderer — is what makes a hive both legible and real. Download Munder Difflin to see the architecture in action; it’s free and open source.

FAQ

What are the two data planes in Munder Difflin?

The terminal plane carries raw pseudo-terminal bytes from each agent's shell (node-pty) to an xterm.js view. The event plane carries structured agent state — Claude Code hook events and routed hive messages — to the office-floor visualization. One is byte-for-byte authentic; the other is event-driven.

Why separate the terminal stream from the event stream?

Each answers a different question. The raw terminal stream shows exactly what the agent output; the event stream tells you which tool is running without parsing that output. Hooks alone miss the stream the user expects to see; the stream alone can't reliably say what's happening. Together they cover both.

How do the planes reach the UI?

Through Electron IPC. The main process owns the PTYs, a hook socket, and the hive; it forwards terminal bytes and structured events to the renderer, where React and Pixi.js draw the terminals and the office floor.

---
